Parameters
|
Data
|
|
Width × Depth × Height (including mobile stand)
|
≤541×354×1557mm
|
|
Weight (including bellows assembly)
|
≤37kg
|
|
touchscreen
|
10.1-inch screen, screen pixels: 1028×800
|
|
Weight Range
|
0.4～150kg
|
|
Peak airway pressure
|
5～50 cmH2O
|
|
Respiratory rate
|
2～60 bpm
|
|
I/E ratio
|
1:1.0～1:4.0
|
|
Tidal volume
|
4～1500ml
|
|
Trigger pressure
|
-10 cmH2O～-0.2 cmH2O
|
|
Trigger flow rate
|
0.2L/min～15.0L/min
|
|
PEEP
|
3～20 cmH2O
|
|
Support pressure (only SIMV has this parameter)
|
3～50 cmH2O
|
